| Year | '88-'90 | '88-'91 | '90-'91 |
|---|---|---|---|
| Model | 2.0 S | 2.0 Si | Si |
ENGINE | |||
| Type | Aluminum-alloy in-line 4 | Aluminum-alloy in-line 4 | Aluminum-alloy in-line 4 |
| Displacement (cc) | 1958 | 1958 | 2056 |
| Horsepower@rpm (SAE net, MT/AT) | 104@5800/105@5800 | 135@6200 | 140@5800 |
| Torque (lb.ft. @ rpm) | 111@4000 | 127@4000 | 135@5000 |
| Compression Ratio | 9.1:1 | 9.0:1 | 9.4:1 |
| Valve Train | SOHC, 12-Valve | DOHC, 16-Valve | DOHC, 16-Valve |
| Fuel Induction System | Dual Sidedraft Constant Velocity | Multi-Point Programmed Fuel Injection (PGM-FI) | Multi-Point Programmed Fuel Injection (PGM-FI) |
| Ignition System | Electronic | Electronic | Electronic |
DRIVE TRAIN | |||
| Type | Front-Wheel Drive | Front-Wheel Drive | Front-Wheel Drive |
| Manual Transmission | 5-Speed | 5-Speed | 5-Speed |
| Electronically Controlled AT (available) | 4-Speed w/Sport-Shift | 4-Speed w/Sport-Shift | 4-Speed w/Sport-Shift |
| Final Drive Ratio (MT/AT) | 4.27/4.13 | 4.27/4.13 | 4.27/4.36 |
BODY/SUSPENSION/CHASSIS | |||
| Body Type | Unit Body | Unit Body | Unit Body |
| Suspension | 4-Wheel Double Wishbone w/Coil Springs | 4-Wheel Double Wishbone w/Coil Springs | 4-Wheel Double Wishbone w/Coil Springs |
| Stabilizer Bar (mm, front/rear | 25.4/17.0 | 25.4/17.0 | 25.4/17.0 |
| Steering Type | Variable-Assist Power Rack-and-Pinion | Variable-Assist Power Rack-and-Pinion | Variable-Assist Power Rack-and-Pinion |
| Steering Wheel Turns, Lock-to-Lock | 2.81 | 2.81 | 2.81(2.66**) |
| Turning Diameter, Curb-to-Curb (ft.) | 34.8 | 34.8 | 34.8(31.5**) |
| Brakes | 4-Wheel Power-Assisted Disc | 4-Wheel Power-Assisted Disc | 4-Wheel Power-Assisted Disc |
| Wheels | 13-inch Steel Wheels w/Full Covers | 14-inch Steel Wheels w/Full Covers | 14-inch Steel Wheels w/Full Covers |
| Tires | 185/70 HR13 | 195/60 R14 85H | 195/60 R14 85H Michelin MXV |
EXTERIOR DIMENSIONS | |||
| Wheelbase (in.) | 101.0 | 101.0 | 101.0 |
| Length (in.) | 177.6 | 177.6 | 177.6 |
| Width (in.) | 67.3 | 67.3 | 67.3 |
| Height (in.) | 51.0 | 51.0 | 51.0 |
| Track (in., front/rear) | 58.3/57.9 | 58.3/57.9 | 58.3/57.9 |
| Curb Weight (lbs., MT/AT) | 2566/2606 | 2639/2674 | 2690/2725 |
| Coefficient of Drag (Cd) | .34 | .34 | .34 |
INTERIOR DIMENSIONS | |||
| Headroom (in., front/rear) | 36.9/34.1 | 36.9/34.1 | 36.9/34.1 |
| Legroom (in., front/rear) | 43.1/27.1 | 43.1/27.1 | 43.1/27.1 |
| Shoulder Room (in., front/rear) | 53.1/51.1 | 53.1/51.1 | 53.1/51.1 |
| Hiproom (in., front/rear) | 51.5/45.1 | 51.5/45.1 | 51.5/45.1 |
| Cargo Volume (cu. ft.) | 11.0 | 11.0 | 11.0 |
| Interior Volume (cu. ft.) | 87 | 87 | 87 |
CAPACITIES | |||
| Engine Oil with Filter (qt.) | 5.1 | 5.1 | 5.1 |
| Fuel (gal.) | 15.9 | 15.9 | 15.9 |
| Cooling System (qts., MT/AT) | 6.3/5.6 | 6.7 | 6.7 |
